SPECIFICATIONS

​

• Engine: 4-stroke, single cylinder, air cooled EPA certificated

• Displacement: 200cc

• Max HP: 6.3hp/3600rpm

• Max torque: 9.6 lb ft/2500rpm

• Bore x stroke: 2.6 x 2.1 inches

• Max speed: 31 mph

• Climbing ability: 12 degrees

• Ignition: C.D.I

• Starting system: Electric / Pull backup

• Battery: 12V 9Ah

• Carburetor: JF (RX)

• Engine oil: SG15W-40

• Clutch: Automatic CVT with Reverse

• Driveline / Driving Wheel: Chain / Dual wheel drive

• Suspension, F / R: Double A-Arm / Double Oil Damped Shock

• Brakes, F / R: No / Hydraulic Disc

• Tires, F / R: 16x6-8 / 16x7-8

• Fuel capacity: 1 gal

• Gross Weight: 386 lbs.

• Net Weight: 330 lbs.

• Max load: 400 lbs.

• Wheelbase: 48.4 inches

• Dimensions (inches): 67L x 43.3W x 51.2H

• Shipping Dimensions (inches): 70L x 44W x 34H

• Height to seat: 10.2 inches

• Min ground clearance: 2.8 inches

• Pedal to seat back distance: 34-39 inches
