Specifications

 Model Number:  ATV-3175U2

 Engine Type:  Single cylinder, 4-stroke, air-cooled

 Displacement:  170cc

 Max Torque:  9.2.N.m/6,000r/min (N.m/r/min)

 Max Power:  6.5kW/8,000r/min (N.m/r/min)

 Bore Stroke: 57.4 x 57.8mm

 Ignition:  CDI

 Starting System:  Electric

 Battery:  12V, 9Ah

 Clutch:  CVT Automatic

 Transmission:  Chain, rear wheel drive

 Brakes Front/Rear:  Hub/hydraulic disc

 Tires Front/Rear:  23 x 7 – 10 / 22 x 10 – 10

 Fuel Capacity:  5.6L

 Weight:  (G.W./N.W) 183 kg/164 kg

 Wheelbase:  1215mm

 Dimensions:  1524 x 812.8 x 762 mm

 Height to Seat:  620mm

 Min. Ground Clearance:  165mm


​

​​
